 Features
- 60 ppm digital Printing / Copying
- Standard network printer / Scanner / Internet Fax
- Standard Document Handling Software
- Maximum 6,250-sheet paper capacity with optional trays and cassettes
- Easy to Use Graphical Interface
- Advanced Security Features
|
Specifications
Specifications - Multifunction Modes
| Copier Function |
Standard |
| Standard Printer Function |
Panasonic Printing System for Windows® |
| Fax Function |
Option |
| Internet Fax/Scan to Email Function |
Standard |
| Scanner Function |
Standard |
Specifications - General
| Automatic Document Feeder (Option) |
70 sheets (A4, 80 g/m˛) |
| Paper Feed |
Std. 1,550-sheet paper tray + 550-sheet paper tray + 50-sheet bypass
Max. 6,250 sheets with option |
| Paper Weight |
Paper Tray: 60 to 90 g/m˛
Bypass Tray: 55 to 133 g/m˛ |
| System Hard Disk (Standard) |
40 GB (Shared) |
| Automatic Duplex Unit |
Standard |
| Power Requirements |
AC 220 V-240 V, 50 Hz/60 Hz |
| Power Consumption |
Max. less than 1.45 kW
Power saver mode: Approx. 180 W
Sleep mode: Approx. 20 W |
| Warm-up Time (20°C) |
Approx. 180 sec. (From Main power switch ON) |
Dimensions (W x D x H)
(Excluding optional equipment) |
600 mm x 757 mm x 900 mm
(Including Automatic Document Feeder and ADF mounting bracket) |
| Weight (Excluding optional equipment) |
Approx. 138 kg |
Specifications - Digital Copier
| Resolution |
Max. 600 dpi |
| Grey Scale |
256 steps |
| First Copy Time |
Approx. 3.5 sec. (A4) |
| Multi Copy Speed |
60 cpm |
| Copy Size |
A3 - A5 |
| Copy Ratio |
Enlargement: (fixed)
200%, 173%, 141%, 122%, 115%
Reduction: (fixed)
87%, 82%, 71%, 58%, 50% |
| Sort Memory Std/Max Capacity |
Standard: 32 MB
Max. 12 GB with optional HDD |
Specifications - Printer
| Network Printer Interface |
Ethernet 10Base-T/100Base-TX |
| Local Printer Interface |
Bi-Directional Parallel |
| Printer Language |
Standard: Panasonic Printing System for Windows
Option: PCL 5e Emulation, PCL 6 Emulation
Adobe(R) PostScript(R)3TM |
| Printing Speed |
60 ppm |
| Paper Size |
A3 - A5 |
| Printing Resolution |
1,200 dpi equivalent x 600 dpi (PCL, PS), 600 dpi x 600 dpi , 300 dpi x 300 dpi (GDI, PCL, PS) |
| Printer Memory |
50 MB |
| PCL/PS Spool Memory |
6 GB with optional HDD |
| Compatible Operating Systems |
Windows(R) XP, 2000, Vista, Server(R) 2003, 98, Me, Windows NT(R) 4.0,
MacOS 8.6-10.4 (PS3 Only) |
Specifications - Network Scanner / Scan-to-Email
| Network Interface |
Ethernet 10Base-T/100Base-TX |
| Maximum Scanning Size |
A3 |
| Scanning Speed |
Approx. 60 opm (Original per minute)
(A4 portrait with ADF) |
| Scanning Resolution |
150 dpi x 150 dpi, 300 dpi x 300 dpi, 600 dpi x 600 dpi |
| Data Format |
TIFF, PDF |
| Address Book Capacity |
200 stations
Max. 1000 stations with optional HDD |
Specifications - G3 Fax (Option) / Internet Fax
| Compatibility |
G3 Fax: ITU-T Group 3, ECM
Internet Fax: ITU-T T.37, IETF RFC 3965 |
| Communication Protocol |
TCP/IP, SMTP, POP3, LDAP (Internet Fax) |
| Modem Speed |
33.6 kbps - 2.4 kbps with automatic fallback (G3 Fax) |
| Coding Scheme |
JBIG / MMR / MR / MH |
| Scanning Speed |
Approx. 0.7 sec. (A4 portrait in Standard or Fine mode with ADF) |
| Transmission Speed |
Approx. 2.9 sec. (A4) |
| Maximum Original Size |
A3 |
| Effective Scanning Width |
292 mm |
| Recording Resolution |
600 x 600 dpi |
| Standard Memory |
3 MB (approx. 180 pages based on ITU-T Image No.1 using Standard Resolution) |
| Optional Memory |
4 MB (320 page) - 8 MB (640 page) |
| Data Format |
TIFF-FX (Profile S/F/J) (Internet Fax) |
